protective mesh
OZA-SEM, OZA-SEB
The OZA-SEM (SEB) protective mesh is designed to prevent external mechanical impact and the ingress of foreign objects larger than 50 mm into OZA series axial fans.
Protection level — IP1X.
The OZA-SEM (small) mesh is installed at the outlet, while the OZA-SEB (large) mesh is mounted at the free inlet side of the fan.
The protective mesh consists of a mounting flange and a welded or woven wire grid.
